Removal and Replacement 7-29
Power Supply (HP3000/979KS, HP9000/Kx50/Kx60/Kx70/Kx80,
and HP VISUALIZE Workstation Models)
Removal: Refer to Figure 7-24
1. Loosen the six captive screws (1) along the top and bottom of the power supply unit.
2. Pull the extractor levers (2) out. Using the extractor levers, pull the power supply unit out from the
chassis.
3. Grasp the power supply unit by the handle (3) and remove it from the chassis.
Figure 7-24 1700VA Power Supply Removal
Caution
The power supply unit is extremely heavy. Be careful removing and lifting the unit to avoid damage to the power
supply.
