Specifications A-3
1
The power supply auto-ranges to the AC voltage and frequency. It does not have to be reconfigured to oper-
ate over its rated operating ranges.
2
The typical AC Input Power rating is based on a configuration of 3 CPUs, 3 internal disks, 1 memory con-
troller, 288Mb of memory, 2 HP-HSC cards, 1 HP-HSC expansion card, 1 HP-PB FDDI and 1 F/W SCSI
card.
Table A-2. Electrical Specifications, HP 3000 and HP 9000
Description Specification
AC Input Voltage Range
1
100 to 127 VAC or 200 to 240 VAC
HP 9000 Kx50/Kx60/Kx70/Kx80
and HP3000 979KS
90 to 143 VAC or 180 to 269 VAC
AC Input Line frequency
1
50 to 60 Hz
AC Input Current 12.5 A (max load at 100 VAC)
10.5 A (max load at 120 VAC)
6.0 A (max load at 200 VAC)
HP 9000 Kx50/Kx60/Kx70/Kx80
and HP3000 979KS
19.5 A (max load at 100 VAC)
16.0 A (max load at 120 VAC)
10.0 A (max load at 200 VAC)
AC Inrush Current 16 A peak, one cycle
HP 9000 Kx50/Kx60/Kx70/Kx80
and HP3000 979KS
48.65 A peak @ 140 VAC/60Hz
AC Input Power
1250 watts maximum, 525 watts typical
2
HP 9000 Kx50/Kx60/Kx70/Kx80
and HP3000 979KS
1700 VA maximum
Power Supply Output Rating 925 watts DC continuous
HP 9000 Kx50/Kx60/Kx70/Kx80
and HP3000 979KS
1200 watts DC continuous
Holdup without system reset 25ms at 50/60Hz (1 cycle, or 500ms)
HP 9000 Kx50/Kx60/Kx70/Kx80
and HP3000 979KS
20ms at 50/60Hz (1 cycle, or 500ms)
Battery Backup Time 15 minutes (with optional external PowerTrust UPS, without
optional UPS there is no battery backup)
Table A-3. DC Voltage Specifications, HP 3000 and HP 9000
Nominal
Voltage
Minimum
Voltage
Maximum
Voltage
Minimum
Current
Maximum
Current
Peak to Peak
Ripple
+3.3V +3.3V +3.4V 0.0A 20A 50mV
+5V +5.1V +5.25V 22A 110A 50mV
+4.4V +4.4V +4.53V 0.0A 27.0A 50mV
+12V +11.64V +12.6V 0.0A 15.0A 100mV
-12V -11.64V -12.6V 0.0A 4.0A 100mV
