Install and Configuration 2-11
Table 2-3. HP9000 Kx70/Kx80 Path Addressing
1.
HP9000/K5x0 only
Location/Description Device Type Address Path
Core I/O card FW DIFF SCSI connector FW DIFF SCSI devices 10/0. (device addr)
Internal Peripheral Bay, slot C (boot disk) FW SCSI disk drive 10/0.6
Internal Peripheral Bay, slot D FW SCSI disk drive 10/0.5
Internal Peripheral Bay, slot E FW SCSI disk drive 10/0.4
Internal Peripheral Bay, slot F FW SCSI disk drive 10/0.3
Core I/O card console connector (MDP port 0) HP 700/96 system console 10/4/0.0
Core I/O card UPS connector (MDP port 1) 1300VA PowerTrust (UPS) 10/4/0.1
Core I/O card MDP connector: ports 2
3
4
5
6
A Modem Distribution Panel
(MDP) is connected to the Core I/O
connector. Supported devices are
then connected to the MDP.
10/4/0.2
10/4/0.3
10/4/0.4
10/4/0.5
10/4/0.6
Core I/O card Internal or external modem con-
nector (MDP port 7)
HP LAM for Internal modem or an
external modem
10/4/0.7
HP-PB 0, slot 1 HP-PB I/O card 10/4/4. (device addr)
HP-PB 0, slot 2 HP-PB I/O card 10/4/8. (device addr)
HP-PB 1, slot 1 HP-PB I/O card 10/16/4. (device addr)
HP-PB 1, slot 2
HP-PB I/O card 10/16/8. (device addr)
Core I/O card, Optional I/O (HSC) connector Graphics console 10/8
Core I/O card, Parallel connector Supported parallel device 10/12/0
Internal Peripheral Bay, slot A SE SCSI CD-ROM 10/12/5.2
Internal Peripheral Bay, slot B SE SCSI DDS Drive 10/12/5.0
Core I/O card, 10 base or AUI connector Appropriate LAN cable 10/12/6
Core I/O card, Keyboard connector graphics option keyboard 10/12/7.0
Core I/O card, Mouse connector graphics option mouse 10/12/8.0
HSC I/O Expansion card, slot 0 HSC I/O card 8/0. (device addr)
HSC I/O Expansion card, slot 1
HSC I/O card 8/4. (device addr)
HSC I/O Expansion card, slot 2
1
HSC I/O card 8/8. (device addr)
HSC I/O Expansion card, slot 3
1.
HSC I/O card 8/12. (device addr)
HSC Dual Bus 4-slot I/O card, slot 0
1.
HSC I/O card 12/0. (device addr)
HSC Dual Bus 4-slot I/O card, slot 3
1.
HSC I/O card 12/12. (device addr)
HSC Dual Bus 4-slot I/O card, slot 2
1.
HSC I/O card 14/8. (device addr)
HSC Dual Bus 4-slot I/O card, slot 3
1.
HSC I/O card 14/12. (device addr)
