HP 54620A - To Recall a Trace Waveform

To recall a trace waveform
1
Press
Trace
.
2
Press the
Trace
softkey to choose either
Mem1
or
Mem2
.
Mem1
and
Mem2
correspond to the two pixel memories in which a waveform
might have been saved.
3
Recall the contents of pixel memory:
•
To recall the waveform and the instrument setup that was in effect when
the waveform was stored, press
Recall Setup
.
The Recall Setup softkey will be either
Recall Mem1 Setup
or
Recall Mem2 Setup
, depending on the memory chosen in step 2.
•
To recall only the stored waveform, press the
Trace Mem
softkey until
On
is highlighted.
Trace Mem will be either
Trace Mem1
or
Trace Mem2
, depending on
which memory was chosen in step 2. You can turn off the memory by
pressing the Trace Mem softkey until
Off
is highlighted.
