To assign colors to channels
1
Press
Label
. Look at the
Assign Channel Colors
softkeys.
The single channel softkey is highlighted in color. This softkey is used to
assign one color to a single channel. The softkey just to the left is used to
assign one color to a group of channels. The activity indicator for each
displayed channel has the same color assigned to the channel.
2
Press the single channel softkey, labeled
X CHXX
(where X is the
selected channel number). Press it again, and rotate the Select knob
to cycle through the channels and select the one you want.
Pressing this softkey increments the channel number.
3
Press
Next Color
.
The channel highlights in the selected color. Continue to set as many
channels to the colors you want.
4
Press
Chan 0-3
. The softkey highlights. Press it a few more times and
it changes to
Chan 4-7
,
Chan 8-11
, and
Chan 12-15
.
If all four channels in a group are assigned the same color, the softkey shows
that color when you select it. If the channels in the group vary in color, the
softkey is white.
5
Press
Next Color
. Continue to press this softkey to view the
waveform colors currently available.
The channel group softkey appears in the selected color, and the channels in
the group, if displayed on the screen, also display in the selected color.
Changing the color for a channel group will change the color for all channels
in the group, even if not all of the channels are displayed on the screen.
Colors Coordinate to Display Activity and Selections
When using colors on the HP 54620C color Logic Analyzer, all of the activity for a
specific channel, including the channel color assignment softkey, channel
waveform, channel activity indicator, and trigger condition indicator (when
defined for the same channel) are displayed in the same color on screen.
The following figure shows the HP 54620C with the Label menu selected and
the Assign Channel Colors softkeys displayed.
Getting Started
To assign colors to channels
33
