Testing the Analyzer
WARNING
Hazardous voltages are on the CRT, power supply, and display sweep board.
To avoid electrical shock, disconnect the power cord from the logic
analyzer. Wait at least three minutes for the capacitors in the logic analyzer
to discharge before you begin disassembling the logic analyzer. Read the
Safety Summary at the back of this manual before beginning disassembly.
A set of built-in tests helps you verify general analyzer performance.
These include the following:
• ROM and RAM self-tests
• Keyboard test
• Acquisition system test
151
