Removing and Replacing Assemblies
WARNING
Hazardous voltages are on the CRT, power supply, and display sweep board.
To avoid electrical shock, disconnect the power cord from the logic
analyzer. Wait at least three minutes for the capacitors in the logic analyzer
to discharge before you begin disassembling the logic analyzer. Read the
Safety Summary at the back of this manual before beginning disassembly.
CAUTION
Do not replace assemblies with the logic analyzer turned on, or damage to
the components can occur.
Refer to the exploded view of the logic analyzer, figure 60, for details on how
the logic analyzer fits together. To install an assembly, follow the instructions
in reverse order.
You will need the following tools to disassemble the logic analyzer:
• T15 TORX driver to remove the logic analyzer from the cabinet and
to remove the fan.
• T10 TORX driver to remove the assemblies from the deck.
• Flat-blade screwdriver to remove the front panel and power shaft
and the optional interface modules and pouch.
You can remove any of the following seven assemblies: fan, front
panel, display, system board, power supply, keyboard, and handle.
181
