HP 54620A - To Define a New Label

To define a new label
1
Press
Label
.
2
Press the
Define Labels
softkey.
A label definition menu is shown on the right-hand side of the display.
3
To use an existing label as the basis for the new label, use the Entry
knob to choose a label from the list of labels. Then press the
Copy
softkey.
The Entry knob moves the cursor through the label list, then through the
character list. The label list includes all predefined labels, and custom labels
you have defined, unless it is re-initialized. When you press the Copy softkey,
the selected label is transferred to the entry field.
4
To enter characters into the new label:
a
Press the
Position
softkey until the cursor position in the entry field
corresponds to the point where you want to replace a character.
b
Enter or delete a character.
•
To enter a character, use the Entry Knob to choose a character from
the character list. Then press the
Copy
softkey.
•
To insert a space, press the
Insert Space
softkey.
•
To delete the current character, press the
Delete Character
softkey.
Delete Character
deletes the character under the cursor and
moves successive characters forward by one position.
5
Press the
Assign Label
softkey.
The label is assigned to the selected channel.
Label display is automatically enabled when you enter the Define Labels
menu. Thus, if the labels were off, they are turned on while you define labels.
If you exit the Define Labels menu, and the labels were off before you
entered the menu, they are turned off when you exit.
Making Analyzer Measurements
To define a new label
62
