HP 54620A User Manual

To remove the system board
1
Using the T10 TORX driver, remove the eight screws that hold the
system board to the deck.
2
Remove the two screws from the rear-panel interface connector.
3
Disconnect the three ribbon cables and the calibration cable.
4
As you remove the system board, rotate the system board so that the
BNCs clear the front panel.
Replaceable Parts
To remove the system board
186

HP 54620A Specifications

General

Category	Measuring Instruments
Model	54620A
Manufacturer	HP
Type	Oscilloscope
Bandwidth	100 MHz
Channels	2
Vertical Sensitivity	2 mV/div to 5 V/div
Vertical Resolution	8 bits
Interface	GPIB, RS-232
Power Requirements	100-240 VAC, 50/60 Hz
Display	Color LCD
Trigger Modes	Edge, Pulse, Pattern
Input Impedance	1 MΩ || 15 pF
