To power-on the logic analyzer
1
Connect the power cord to the rear of the
HP 54620A/C, then to a suitable ac voltage source.
The HP 54620A/C power supply
automatically adjusts for input line voltages
in the range 100 to 240 VAC. Therefore, you
do not need to adjust the input line voltage
setting. The line cord provided is matched
by HP to the country of origin of order.
Ensure that you have the correct line cord.
See table 1.
2
Press the power switch.
The HP 54620A/C performs a self-test, then
shows the display. The instrument is ready
to use.
Getting Started
To power-on the logic analyzer
27
