HP 54620A - Using Labels and Colors

Using Labels
The HP 54620A/C allows you to define and assign labels to each input
channel. Or, you can turn labels off to increase the waveform display
area.
In addition, the HP 54620C allows you to assign colors to channels.
This makes it easy to associate input channels with their functions in
the system under test.
To turn the label display on or off
•
To display channel labels, press
Label
, then press the
Labels
softkey until
On
is highlighted.
•
To turn off channel labels display, press
Label
, then press the
Labels
softkey until
Off
is highlighted.
•
To toggle the channel labels display, press
Label
repeatedly
until the labels are on or off as desired.
The following figure shows the HP 54620C color logic analyzer label menu.
You can highlight an individual channel or a set of channels.
