Page #83 background imageLoading...
Page #83 background image
To show both main and delayed sweep displays
1
Press
Main/Delayed
.
2
Press the
Delayed
softkey.
The display is divided into a main and delayed sweep. The delayed sweep is
shown in the bottom half and represents the portion of the waveform
indicated by the vertical lines outlining a window in the upper half.
The Time/Div setting for the delayed sweep is independent of the main
sweep, except that it can be no slower than twice the speed of the main
sweep. It is adjusted using the Time/Div knob. Figure 20 shows the Time/Div
indicator for the delayed sweep. If you need to change the Time/Div for the
main sweep, you must change back to Main before using the Time/Div knob.
Making Analyzer Measurements
To show both main and delayed sweep displays
82
