HP 54620A - To Remove the Cabinet

To remove the cabinet
1
Turn off the logic analyzer and disconnect the power cable.
2
If a module is installed, remove it from the logic analyzer.
3
Using the T15 TORX driver, remove the two screws from the rear of
the cabinet.
4
Using your thumbs, gently push on the rear-panel connector to slide
the logic analyzer out of the cabinet.
Replaceable Parts
To remove the cabinet
182
