HP 54620A - Page 37

HP 54620A Logic Analyzer Front Panel
Trigger
Keys
Display Channel
Controls
General
Controls
Horizontal
Controls
Storage
Keys
Softkeys
HP 54620C
does not have
display
intensity
Signal
Inputs
Trigger
Input /
Output
Figure 6
Getting Started
Learn the front panel
36
