Making Analyzer Measurements
The HP 54620A/C provides a full set of features to help automate your
measurement tasks. You can:
• Set up the analyzer for different logic thresholds, allowing
simultaneous timing measurements on sets of signals from different
logic families.
• Modify the way the analyzer acquires data.
• Label input signals to make it easier to relate the display to the
circuit under test.
• Set up simple or complex trigger conditions, as needed, to capture
only the sequence of events you want to examine.
• Use delayed sweep to examine the waveforms of interest.
• Make measurements on a single waveform or on one waveform with
respect to another.
• Trigger the analyzer from other instruments or use the analyzer to
trigger other instruments.
• Save the measurement for comparison with others or save the
analyzer configuration for later use in making the same
measurement.
This chapter explains how to do all these things and more. If you are
not familiar with basic analyzer operations, see chapter 1, “Getting
Started.”
