HP xw4300 User Manual

Connector Pins132
C.1 Enhanced Keyboard
C.2 Mouse
C.3 Ethernet RJ-45
C.4 Serial Interface
C.5 USB
Keyboard Connector Pin Signal
1
2
3
Data
Unused
Ground
4
5
6
+5 VDC
Clock
Unused
Mouse Connector Pin Signal
1
2
3
Data
Unused
Ground
4
5
6
+5 VDC
Clock
Unused
Ethernet Connector Pin Signal
1
2
3
4
(+) Transmit Data
(-) Transmit Data
(+) Receive Data
Unused
5
6
7
8
Unused
(-) Receive Data
Unused
Unused
Serial Connector Pin Signal
1
2
3
Carrier Detect
Receive Data
Transmit Data
4
5
6
Data Terminal Ready
Signal Ground
Data Set Ready
7
8
9
Request to Send
Clear to Send
Ring Indicator
USB Connector Pin Signal
1
2
3
4
+5 VDC
- Data
+ Data
Ground
