Product Overview20
1.5 Environmental Specifications
The following table describes the environmental specifications.
Table 1-8 Environmental Specifications
Temperature Operating: 5 to 35°C (40 to 95°F)
Non-operating: -40 to 60°C (-40 to 140°F)
Humidity Operating: 8 to 85%RH, non-condensing
Non-operating: 8 to 90%RH, non-condensing
Altitude Operating: 0 to 10,000 ft (3048m)
Non-operating: 0 to 30,000 ft (9144m)
Shock Operating ½-sine: 40g, 2-3ms
Non-operating:
½-sine: 160 cm/s, 2-3ms, (~100g)·
square: 605 cm/s, 30 G
NOTE: The values represent individual shock events and are not indicative of repetitive shock
events.
Vibration Operating Random: 0.5g (rms), 5-300 Hz
Non-Operating:
random: 2.0 g (rms), 10-500 Hz·
NOTE: The values are not indicative of continuous vibration.
