Product Overview
19
1.4.3 Power Consumption and Cooling
The following table shows the power consumption for a typical configuration based on primary power consumptions:
• One processor (1 x 3.6 GHz 2M L2 Pentium 4 Processor with HT Technology)
• One GB memory (2 x 512 MB)
• Two hard drives (2 x SATA 40 GB)
• CD-ROM drive
• PCI Express Graphics Card (NVIDIA FX 1400)
• One diskette
• Monitor (A monitor is attached. The system does not provide power to the monitor.)
NOTE: To reach zero power consumption, either unplug the workstation from the power outlet or use a power strip with
a switch. However, removing all power to the workstation might reduce the life of the real-time clock battery.
For more information on power-saving features, refer to your operating system documentation.
1.4.4 System Fans and Airflow
The workstation includes a rear system fan, one processor heatsink fan, one power supply fan, plus an optional front
system fan.
1.4.5 Resetting the Power Supply
If an overload triggers the power supply overload protection, all power is immediately cut. To reset the power supply unit:
1. Disconnect the power cord.
2. Determine what caused the overload and fix the problem.
3. Reconnect the power cord and reboot the workstation.
When you power down the workstation through the operating system, power consumption falls below the low power
consumption but does not reach zero. This on/off feature extends the life of the power supply.
Heat Dissipation Typical is 733.8btu/hr
Maximum is 2415.4btu/hr
Power Supply Fan 92mm variable speed
Power Supply Dimensions 9.76cm (3.843 in) wide
15cm (5.906 in) high
15.371cm (6.052 in) deep
ENERGY STAR Compliant Available as an option
Built-in Self Test LED Yes
Surge Tolerant Full Ranging Power Supply Withstands power surges up to 2000V
Table 1-7 HP xw4300 Workstation Power Consumption and Cooling for Specified Configuration
Input Power Consumption 120VAC/60Hz
Typical operating mode (system busy) 215W/733.8btu/hr
Windows XP Idle 107W/365.2btu/hr
Standby mode (S3) ~4W
Hibernate mode (S4) ~3W or less
Power Off (S5) ~3W or less
Table 1-6 Power Supply Specifications
