HPE Synergy Series

Component and LED identification
Frame front components and device bays
Item Description
1 Device bays—Compute modules and storage modules
2 Front panel—Provides access to the HPE Synergy console, via KVM or laptop.
3 Appliance bays
Front panel components
70 Component and LED identification
