Item Description Function
1 UID LED
Press the UID button to illuminate the blue locator LED.
• Solid blue—Illuminates to locate the appliance module.
• Flashing blue—Indicates appliance module firmware
update. Do not power off or remove appliance module when
the UID LED is flashing.
2 Health LED
Indicates the health of the appliance module
• Solid green—Normal operation
• Flashing amber—Warning
• Flashing red—Critical error
The appliance Health LED provides health status of the
appliance. If the Health LED indicates a warning or a critical
error, connect to the Synergy console to troubleshoot.
3 Activity LED
Indicates which appliance module is active.
• Off—Indicates that the appliance module is the standby in a
Highly Available configuration or HPE OneView is in an error
state.
• Solid green—Indicates that the appliance module is active.
• Flashing green—Indicates that the reset button has been
pressed and held for greater than 10 seconds, which
initiates a reimaging of the appliance module. The active
LED does not continue to flash green during the reimaging
process.
4 Power LED
Indicates power to the appliance
• Off—No power. Verify that the appliance module is fully
inserted into the frame link module.
• Flashing amber—Appliance module is initializing.
• Solid amber—Appliance module is powered off.
• Solid green—Appliance module is powered on.
5 Reset button
Using an applicator such as a paper clip, press the recessed
button to reset the appliance module.
• Press and release—Resets the appliance module.
• Press and hold until activity LED is flashing green—Initiates
reimaging of the appliance module from files on the USB
flash drive plugged into the appliance module.
6 USB port USB 3.0 port for connecting a USB drive to flash a USB
recovery image.
72 Component and LED identification
