Parts List
9
XPR300 Instruction Manual 809480 365
5 127344 Coolant filter housing 1
027005 Coolant filter (fine) 1
6 229777 Coolant hose (1 inch) 1
7 428729
Coolant pump and motor assembly:
Adapter: 1-5/8 inch X 1 inch NPT X #16 JIC
Plug with O-ring
Coolant pump screen (coarse)
Pump and motor
Adapter: 1 inch MNPT X 1 inch MNPT hexagonal collar
Adapter: 1 inch MNPT X 3/8 inch FNPT X 1/4 inch FNPT
Adapter: 3/8 inch hexagonal
Coolant solenoid valve assembly
1
8 006132 Coolant bypass check valve 1
9 229721 Coolant solenoid valve assembly 1
10 229654 Thermistor: Copper pipe clip with electrical connector 1
11 127559 Coolant pump screen (coarse) 1
12 229843 Plug and O-ring 1
13 002561 Coolant reservoir 1
14 006113 Coolant check valve 1
428330 Kit: Tubing (1 inch hose not included) 1
Part number Description Quantity
