Hypertherm XPR300 User Manual

Parts List
9
XPR300 Instruction Manual 809480 367
Other adapters not shown
Part number Description Location Quantity
015669
Male adapter: 3/8 inch NPT X 1/2 inch
tube
in coolant solenoid valve 1
006099
Coolant drain valve: 1/4 inch NPT X
3/8 inch tube
in the bottom of the coolant
reservoir
1
015073 Adapter: 1/4 inch NPT X 1/4 FPT
in the bottom of the coolant
reservoir
1
015738
Elbow adapter: 1/4 inch NPT X
1/2 inch tube, 45° swivel
in the top of the coolant
reservoir
1
015510 Adapter: 1/4 inch X hexagonal collar
between the flow meter and
coolant reservoir
1
015663 Adapter: 1/4 inch NPT X 1/2 inch tube
in the flow meter and coolant
bypass check valve
2
015668
Elbow adapter: 1/2 inch NPT X
1/2 inch tube, 90°
in the coolant filter (fine)
assembly
2
104 807 Nut for chopper fitting on the back of choppers 4
015815
Elbow fitting: 1/2 inch tube X 1/2 inch
tube, 90°
on the back of the choppers (4)
and the heat-exchanger inlet (1)
5
015820 Fitting: 1/2 inch tube X 1/2 inch tube heat-exchanger outlet 1

Hypertherm XPR300 Specifications

General

Cutting Current	300 A
Duty Cycle	100% at 300 A
Technology	X-Definition Plasma
Gas Supply	Oxygen, Nitrogen, Air
Cutting Capacity (Mild Steel)	38 mm (1.5 in)
Severance Capacity (Mild Steel)	75 mm (3 in)
Pierce Capacity (Mild Steel)	50 mm (2 in)
Input Voltage	200–480 V, 3-PH, 50/60 Hz
