Hypertherm XPR300 User Manual

Parts List
9
XPR300 Instruction Manual 809480 379
Part number Description Quantity
1 229793 Manifold: Gas input (no adapters) 1
2 104843 Manifold: Gas output (no adapters) 1
3 229844 Water regulator 1
4 006157 Check valve 4
Push-to-connect adapters
5 015905 1/8 inch NPT X 1/4 inch tube 1
6 015853 Elbow: 1/4 inch NPT X 5/16 inch tube 1
7 015876 1/4 inch NPT X 1/4 inch tube 1
8 015907 1/4 inch NPT X 3/8 inch tube 1
9 015909 Elbow: 3/8 inch NPT X 5/16 inch tube 1
10 015910 3/8 inch NPT X 5/16 inch tube 1
11 015906 Dual connection: 1/8 inch NPT X 1/4 inch tube 1
12 015908 Elbow: 1/4 inch NPT X 3/8 inch tube 1
Threaded adapters with thread sealant applied
13 015103 1/4 inch NPT X RH ‘B’ inert female 3
14 015012 1/4 inch NPT X #6 male 3
15 015009 1/4 inch NPT X RH ‘B’ male 1
16 015922 1/4 inch X hexagonal collar 5
17 015230 1/4 inch NPT X LH ‘B’ 1
18 015116 1/8 inch NPT X RH ‘A’ 1
19 015210 1/8 inch NPT X LH ‘A’ 1
20 015197 1/8 inch NPT X #5 1

Hypertherm XPR300 Specifications

General

Cutting Current	300 A
Duty Cycle	100% at 300 A
Technology	X-Definition Plasma
Gas Supply	Oxygen, Nitrogen, Air
Cutting Capacity (Mild Steel)	38 mm (1.5 in)
Severance Capacity (Mild Steel)	75 mm (3 in)
Pierce Capacity (Mild Steel)	50 mm (2 in)
Input Voltage	200–480 V, 3-PH, 50/60 Hz
