1.2 Mechanical specifications
1-11
1. Specifications
Moment offset datum position
Caution
If the actuator is used with excessive allowable moment and overhang load, it may not
only lead to abnormal noise and vibration but also significantly reduce the life of the
ELECYLINDER.
Allowable moment
offset datum position
90
5832
