Installing the Frame Kit: The following tables show the parts required for each of the tie-down kits (a
non-raised floor, short-raised floor, and a long-raised floor).
Rack Tie-Down Kits:
11P4759 Frame tie-down Kit (Non-Raised Floor) (RPQ 8A1183)
Item Part Number Qty Description
Item 3 in illustration on page 109. 11P3527 2 Shipping bar (lower)
Item 5 in illustration on page 109. 11P3529 4 Hinge plate
Item 8 in illustration on page 109. 11P3530 2 Latch plate
Item 6 in illustration on page 109. 11P3531 2 EQ support
Item 2 in illustration on page 109. 11P3532 2 Shipping bar (upper)
Item 7 in illustration on page 109. 76X4687 2 Latch bolt
Item 1 in illustration on page 109. 1624804 20 Screw (hex flange, 20mm, long)
Item 9 in illustration on page 109. 1621546 8 Screw (hex, 25mm, long, hinge)
Item 10 in illustration on page 109. 1622307 8 Washer (M8, hinge)
Item 1 in illustration on page 110. 11P3528 2 Plate lock-down
Item 2 in illustration on page 110. 05N6345 4 Spacer
Item 4 in illustration on page 110. 05N6344 4 Bushing
Item 5 in illustration on page 110. 21L4309 4 Washer
Item 3 in illustration on page 110. 0130985 4 Washer
Item 6 in illustration on page 110. 05N6346 4 Bolt
11P4757 Frame tie-down Kit (Short - Raised Floor) (RPQ 8A1185)
Item Part Number Qty Description
Illustration on page 114. 44P0673 4 Turnbuckle Assembly (short)
Item 3 in illustration on page 109. 11P3527 2 Shipping bar (lower)
Item 5 in illustration on page 109. 11P3529 4 Hinge plate
Item 8 in illustration on page 109. 11P3530 2 Latch plate
Item 6 in illustration on page 109. 11P3531 2 EQ support
Item 2 in illustration on page 109. 11P3532 2 Shipping bar (upper)
Item 7 in illustration on page 109. 76X4687 2 Latch bolt
Item 1 in illustration on page 109. 1624804 20 Screw (hex flange, 20mm, long)
Item 9 in illustration on page 109. 1621546 8 Screw (hex, 25mm, long, hinge)
Item 10 in illustration on page 109. 1622307 8 Washer (M-8, hinge)
Chapter 2. Physical Characteristics of Systems 107
