16-8
Click [�] to select the firmware file.
Type the IC-7800’s IP address here.
r Select the firmware file, that has “dat” extension (ex-
ample: 7800_300.dat)
.
 •Click[…],thenselectthefile,aswellasthelocation.
t Type the IC-7800’s IP address into “IC-7800 IP Ad-
dress” text box (example: 192.168.0.10).
y Click [Start].
Click to start the
firmware update
u The window as at left appears.
Read the precaution in the window carefully.
i Click [Yes] if you want to start the firmware update.
o The screen as at left is displayed.
 •ThefollowingdialogappearsintheIC-7800display.
R WARNING! NEVER turn the IC-7800 power
OFF at this stage.
The transceiver firmware will be damaged.
Click [OK] to finish the firmware update.
!0 Click [OK] to finish the firmware update.
 •The“FIRMWAREUPDATING”dialogasabovedisap-
pears.
!1 Push [POWER] to turn the IC-7800 power OFF,
then ON again.
16
UPDATING THE FIRMWARE
