Icom IC-7800

16-7
D IP address setting
IMPORTANT! A fixed (static) IP address is used for
the IC-7800.
When you connect the IC-7800 to a LAN, ask the
network manager about a usable/assignable IP
address and the subnet mask in advance.
NEVER set the IP address that has already been
used with another device in the network. If the IP
address is duplicated, the network will crash down.
[F-1•Y]
[F-3•Ω ≈]
[F-5•OTHERS]
[F-7•SET]
[F-2•Z] [EXIT/SET]
q Push [EXIT/SET] several times to close a multi-func-
tion screen, if necessary.
wPush[F-7•SET]toselectsetmodemenuscreen.
ePush [F-5•OTHERS] to select the Others set
mode.
rPush[F-1•Y]/[F-2•Z] several times to select “IP Ad-
dress” item.
t Push[F-3•Ω ≈] to select the desired part then rotate
main dial to set the desired or specified IP address.
 •“192.168.0.10”isthedefaultsetting.
yPush[F-2•Z] to select “Subnet Mask” item.
u Rotate main dial to set the desired or specified sub-
net mask.
 •“255.255.255.0”isthedefaultsetting.
i Push [POWER] to turn the transceiver power OFF,
then ON to effect the IP address and subnet mask
settings.
D Updating from the PC
Click to
continue
q Start up the IC-7800 Firm Utility.
 •Thewindowasatleftappears.
w Read the caution in the window carefully.
e Click [Yes] if you agree and continue the firmware
updating.
16
UPDATING THE FIRMWARE
When updating the firmware from the memory
device, the following settings are not necessary.
The IC-7800 Firm Utility corresponds to the follow-
ing operating systems:
Microsoft® Windows® 98/SE
Microsoft® Windows® ME
Microsoft® Windows® 2000
Microsoft® Windows® XP
 Microsoft®WindowsVista®
Microsoft® Windows® 7
Microsoft® Windows® 8
Microsoft® Windows® 8.1
