3-7
D Selecting 1 Hz step
The minimum tuning step of 1 Hz can be used for fine
tuning.
1Hz step indicator 1Hz step indicator
q Push [TS] to turn the quick tuning function OFF.
w Hold down [TS] for 1 second to turn the 1 Hz tuning
step ON or OFF.
NOTE: 1 Hz tuning step activates for both main and
sub bands simultaneously. Therefore, either [TS]
can be used for the 1 Hz tuning step selection.
D Auto tuning step function
When rotating main or sub dial rapidly, the tuning
speed accelerated automatically as selected.
[F-1•Y][F-2•Z]
[F5•OTHERS]
[EXIT/SET] [F-7•SET]
q Push [EXIT/SET] several times to close a multi-func-
tion screen, if necessary.
wPush[F-7•SET]toselectsetmodemenuscreen.
 •Holdingdown[EXIT/SET]for1secondalsoselectsset
mode menu screen.
ePush[F-5•OTHERS]toentertheOtherssetmode.
rPush[F-1•Y]or[F-2•Z] to select “MAIN DIAL Auto
TS” or “SUB DIAL Auto TS.”
 •“MAINDIALAutoTS”formaindial,“SUBDIALAuto
TS” for sub dial selection.
t Rotate main dial to select the desired condition from
high, low and OFF.
 •HIGH:Approximately 5 times faster when the
tuning step is set to 1 kHz or smaller steps;
approximately 2 times faster when the
tuning step is set to 5 kHz or larger steps.
 •LOW:Approximately2timesfaster.
 •OFF:AutotuningstepisturnedOFF.
y Push [EXIT/SET] to exit the set mode.
3
BASIC OPERATIONS
