D PSK decode set mode
This set mode is used to set the FFT scope setting,
time stamp setting, etc.
• Setting contents
[F-1•Y] Main dial[EXIT/SET][F-2•Z][F-4•DEF]
[F-3•Ω ≈] [F-7•WIDE]
qDuringPSKmodeoperation,push[F-3•DECODE]
to select PSK decode screen.
wPush[F-1•<MENU2>]toselectPSKdecodemenu
2,thenpush[F-6•SET]toselectPSKdecodeset
mode.
 •Push[F-7•WIDE]totogglethescreensizefromnormal
and wide.
ePush[F-1•Y ]or[F-2•Z] to select the desired set
item.
r Set the desired condition using the main dial.
 •Holddown[F-4•DEF]for1secondtoselectadefault
condition or value.
 •Push [F-3•Ω ≈] to select the set contents for some
items.
t Push [EXIT/SET] to exit from set mode.
4
RECEIVE AND TRANSMIT
Turn the time stamp (date, transmission or reception
time) display ON or OFF.
•ON :Displaysthetimestamp.
•OFF :Notimestampdisplay.
Selects the clock display for time stamp usage.
NOTE: The time won’t be displayed when “OFF” is
selected in “PSK Time Stamp” as above.
•Local:Selectsthetimethatsetin“Time(Now).”
•UTC*:Selectsthetimethatsetin“CLOCK2.”
* The name of choice may differ according to
“CLOCK2 Name” setting (p, 11-2). “UTC” is the
default name of CLOCK2.
Set the FFT scope waveform averaging function from
2 to 4 and OFF. (default: OFF)
Recommendation!
If you use the FFT scope waveform for tuning, using
the default or smaller number setting is recom-
mended.
Set the color for the FFT scope waveform.
•ThecolorissetinRGBformat.
•
The set color is indicated in the box beside the RGB scale.
• Push[F-3•Ω ≈] to select R (Red), G (Green) and B (Blue),
and then rotate the main dial to set the ratio from 0 to 255.
Select the AFC (Automatic Frequency Control) func-
tion operating range from ±15 Hz (default) and ±8 Hz.
NOTE: The AFC function may not tune the signal
properly when a weak PSK signal is received.
