Icom IC-7800 - D Meter Type Selection

3-11
D Meter type selection
A total of 3 meter types are available in the IC-7800—
Standard, Edgewise and Bar meters.
Follow the instructions below for the meter type se-
lection.
[F-1•Y] [EXIT/SET][F-7•SET][F-2•Z]
[F-3•DISPLAY]
q Push [EXIT/SET] several times to return to normal
screen, if necessary.
wPush[F-7•SET],thenpush[F-3•DISPLAY]toselect
display set mode.
ePush[F-1•Y]or[F-2•Z] to select “Meter type (Nor-
mal Screen)” item.
r Rotate main dial to select the desired meter type
from “Standard,” “Edgewise” and “Bar.”
t Push [EXIT/SET] to exit display set mode.
• Edgewise meter
• Bar meter
3
BASIC OPERATIONS
