Icom ID-5100A

12
MENU SCREEN
12-6
CallSign Set and display the DV mode call signs.
UR: CQCQCQ, R1: --------,
R2: --------, MY: --------
Displays the operating call signs.
Sets the operating call signs according to the type of
call you want to make.
RX History Displays the received call history in the DV mode.
LAST (MAIN) Displays the calls your transceiver received.
DVMemory Stores call signs or repeater information to use in the DV mode.
Your Call Sign Blank Stores station call signs.
Add or edit call signs.
Repeater List
( See page 7-37 for details of the pre-
loaded data.)
01:~30: Stores repeater information.
Add or edit a repeater information.
NOTE: The repeater list described in this manual may differ from your preloaded list.
My Station Sets and stores your call sign to use in the DV mode.
My Call Sign 1:~6: Stores your own call signs.
Select or edit a call sign to use in the DV mode.
TX Message 1:~5: or OFF Stores TX Messages.
Select or edit TX Message to use in the DV mode.
DV Set Sets values for the DV mode operations.
Tone Control
RX Bass Cut, Normal or Boost Sets the DV mode received audio bass filter level to
Cut, Normal or Boost.
RX Treble Cut, Normal or Boost Sets the DV mode received audio treble filter level to
Cut, Normal or Boost.
RX Bass Boost OFF or ON Turns the DV mode received audio Bass Boost func-
tion ON or OFF
TX Bass Cut, Normal or Boost Sets the DV mode transmit audio bass filter level to
Cut, Normal or Boost.
TX Treble Cut, Normal or Boost Sets the DV mode transmit audio treble filter level to
Cut, Normal or Boost.
Auto Reply OFF, ON, Voice, Position (Main Only)
or Position (Main/Sub)
Selects the Automatic Reply function.
DV Data TX PTT or Auto Selects manually or automatically to transmit low
speed data.
Digital Monitor Auto, Digital or Analog Selects the DV mode RX monitoring when [SQL] is
held down.
Digital Repeater Set OFF or ON Turns the digital repeater setting function ON or OFF.
This function is usable in any DV mode except using
the DR function.
DV Auto Detect OFF or ON Turns the DV mode automatic detect function ON or
OFF.
RX Record (RPT) ALL or Latest Only The transceiver can record the data of up to 50 indi-
vidual calls.
BK OFF or ON Turns the BK (Break-in) function ON or OFF. The BK
function allows you to break into a conversation be-
tween two stations with call sign squelch enabled.
EMR OFF or ON Turns the EMR (Enhanced Monitor Request) com-
munication mode ON or OFF.
After turning OFF the transceiver, the EMR mode will
be cancelled.
EMR AF Level 0~19~32 Sets the audio output level when an EMR mode sig-
nal is received.
Menu items and Default settings (Continued)
NOTE:The default settings shown in bold letters below are for the USA version.
The default settings may differ, depending on your transceiver version.
