Icom ID-5100A

13
OTHER FUNCTIONS
13-5
The transceiver can store up to 16 memory channels of
24-digit DTMF code.
D EnteringDTMFcode
Touch [MENU]. q
Touch “DTMF Memory.” w
(DTMF > DTMFMemory)
• If the item is not displayed, touch [∫] or [√] one or more
times to select another page.
• Displays the DTMF memory channel list (d0 to d#).
Touch the desired DTMF memory channel. e
Enter the desired DTMF code. r
• Touch [] to move the cursor backwards, or touch [] to
move the cursor forwards.
• Touch [CLR] to delete the selected character, symbol or
number.
UsingtheDTMFmemory
After entering, touch [ENT]. t
• Saves the channel, and returns to the “DTMF MEMORY”
screen.
Stored DTMF code
Touch [MENU]. y
• Closes the Menu screen.
You can clear the entered DTMF code.
Touch the DTMF memory channel for 1 second in
step t, and then touch “Clear.”
Channel
to clear
