MENU SCREEN
12-20
GPS Select (Default:InternalGPS)
GPS > GPS Set > GPS Select
Select either the internal GPS receiver that the trans-
ceiver receives its position data from or to manually en-
ter your current position data.
• OFF: A GPS receiver is not used.
• Internal GPS: Position data from the internal GPS
data is used for the GPS functions.
• Manual: Manually enter the current Latitude,
Longitude and Altitude in Manual Posi-
tion.
ManualPosition
(Default: LATITUDE : 0°00’00”N
LONGITUDE : 0°00’00”E
ALTITUDE : ------ft)
GPS > GPS Set > Manual Position
Manually enter the latitude, longitude and Altitude of
your current position.
The received position data can be captured by se-
lecting “Capture From GPS” when position data is
received from the internal. (p. 8-21)
GPS Out (To DATA jack) (Default:OFF)
GPS > GPS Set > GPS Out (To DATA Jack)
Select whether or not GPS information from the inter-
nal GPS receiver is output to the [DATA] jack.
For your information ✓
GPS information is not output from the [DATA] jack
when “GPS Select” is set to “OFF” or “Manual.”
Select “OFF” when you want to operate slow-speed
data communication.
GPS TX Mode (Default:OFF)
GPS > GPS TX Mode
Select a GPS transmission mode to send a GPS data
while in the DV mode.
• OFF: Does not transmit a GPS data.
• D-PRS: Transmits GPS data in the D-PRS format.
• NMEA: Transmits a GPS data in the NMEA format.
UnprotoAddress (Default:API510,DSTAR*)
GPS > GPS TX Mode > D-PRS > Unproto Address
Enter an unproto address of up to 56 alphanumeric
characters.
TXFormat (Default:Position)
GPS > GPS TX Mode > D-PRS > TX Format
Select the format to transmit the position data in the
D-PRS mode.
• Position: The caller station is the mobile or base sta-
tion.
• Object: Transmits a certain location’s information,
such as an event, earthquake, and so on.
• Item: Transmits repeater or antenna information
that needs no time information.
• Weather: Transmits weather information received from
a weather device.
Foruserswhohaveoneofthefollowingmodels:
( ID-800H, IC-91AD/E91, IC-U82, IC-V82, IC-7100, ID-
51A/E, ID-31A/E, IC-9100, IC-80AD/E80D, ID-880H/E880,
IC-92AD/E92D, IC-2820H/E2820)
When you receive a D-PRS position (Base), Object, Item
or Weather signal, position data will not be displayed.
Symbol (Default:Car)
GPS > GPS TX Mode > D-PRS > TX Format > Position
> Symbol
The symbol is an icon which represents your means of
transportation or location. The stored symbol in the se-
lected channel (1 to 4) is transmitted with position data
while in the D-PRS mode.
Editingasymbol
Touch a desired symbol channel between 1 and 4 for q
1 second.
Touch “Edit Symbol.” w
Touch [QUICK]. e
Touch “Direct Input.” r
Touch [+] or [–] to select the first digit. t
• Usable characters: /, \, 0 to 9, A to Z
Touch [+] or [–] to select the second digit. y
• Usable characters: Alphanumeric characters and sym-
bols
Touch [SET]. u
• Sets the Symbol into the channel selected in step q.
Selectingapresetsymbol
Touch a desired symbol channel between 1 and 4 for q
1 second.
Touch “Edit Symbol.” w
Touch a desired Symbol. e
• Touch [∫] or [√] one or more times to select the page.
• Sets the Symbol into the channel selected in step q.
GPSitems
