About these Advanced Instructions (PDF format)
These Advanced Instructions describe the details of the ID-5100A/E features. This PDF formatted manual provides
you with convenient functions, as follows.
NOTE:Below page is used only as an example to describe these advanced instructions.
2
BASIC OPERATION
2-2
Power ON and setting audio volume/squelch level
Turning ON the power D
Hold down [ � ] for 1 second to turn ON the power.
A beep sounds and, after the opening message and pow-
er source voltage are displayed, the operating frequency
appears.
Hold down [
] for 1 second to turn OFF the power.
Y o u can select the opening message display option
in the Menu screen. (p. 12-58)
Display > Opening Message
Y o u can select the power source voltage display op-
tion in the Menu screen. (p. 12-58)
Display > Voltage (Power ON)
[ ]
Setting audio volume and squelch level D
Rotate [VOL] to adjust the audio level. q
The beep level is adjusted in the “Beep Level” item of the
Menu screen. (p. 12-61)
Sounds > Beep Level
Rotate [SQL] until the noise and the “BUSY” icon just w
disappear.
Rotating [SQL] clockwise makes the squelch tight. The
tight squelch is for strong signals.
When rotating [SQL] clockwise beyond the center posi-
tion, [SQL] can be used as ‘S-meter Squelch’ or ‘Attenua-
tor.’ Select the [SQL] option in the Menu screen.
(p. 12-52)
[VOL]
[SQL]
[VOL]
[SQL]
(Sample)
To mute the audio, touch [QUICK] for 1 second. �
Releases mute when rotating [DIAL], [VOL] or
[SQL], or operating a key, touch screen or micro-
phone.
Previous view
•
•
•
•
•
•
Previous view
Movetothepreviouslyreadpage.
Click
Previousview
at the left top on an
each page, to move back to the previ-
ously read page.
(p. 12-58)
Movestothepage,
ifclicked.
Previous view
