6
GPS OPERATION (ADVANCED)
6-41
GPS items
GPS Position (continued)
<3. When the caller’s TX format is D-PRS Position
(Base station)>
Compass*
Displays the caller’s direction from
your location�
Symbol
Displays the caller’s D-PRS
symbol�
Latitude Displays the caller’s latitude�
Longitude Displays the caller’s longitude�
GL
Displays the grid locator based on
the latitude and longitude of the
caller’s location�
ALT Displays the caller’s altitude�
DST
Displays the caller’s distance from
your location�
Call sign
Displays the caller’s call sign
(with SSID)�
POWER
Displays the caller’s TX power level�
HEIGHT
Displays the caller’s antenna height�
GAIN Displays the caller’s antenna gain�
DIRECT
Displays the direction of the caller’s
antenna was pointing�
GPS Time Stamp
Displays the time that the caller
acquired the position data�
<4. When the caller’s TX format is D-PRS Object/
Item>
Compass*
Displays the Object/Item’s direction
from your location�
Symbol
Displays the Object/Item’s D-PRS
symbol�
Latitude Displays the Object/Item’s latitude�
Longitude
Displays the Object/Item’s longitude�
GL
Displays the grid locator based on
the latitude and longitude of the
Object/Item’s location�
ALT Displays the Object/Item’s altitude�
DST
Displays the Object/Item’s distance
from your location�
Object/Item name Displays the Object/Item’s name�
Call sign
Displays the caller’s call sign
(with SSID)�
COURSE
Displays the Object/Item’s direction
over the ground�
SPEED
Displays the Object/Item’s speed�
POWER
Displays the Object/Item’s TX power
level�
HEIGHT
Displays the Object/Item’s antenna
height�
GAIN
Displays the Object/Item’s antenna
gain�
DIRECT
Displays the direction that the
Object/Item’s antenna was pointing�
GPS Time Stamp
Displays the time that the caller
sent the Object’s data�
L When the Object or Item is disabled, “KILLED” is
displayed�
* You can change the display type in the Quick Menu
window�
