EN
5 - ADJUSTMENTS AND SETTING-UP BOSS 332/545/552 HD
5 - Pag. 30 / 34
Bar selector adjustment
Make the adjustment as follows.
• Use screw "B" to adjust the transverse position
of bar stop "A" so that selectors "C" lift just
one bar.
• Open the upper guide channels; the first bar
must be dropped into the guide channels, while
the second bar should be held in the magazine
until the next guide channel closure.
