IEMCA BOSS 545 E - Page 168

10 - GUIDE CHANNELS - BAR PUSHER - REVOLVING TIPS BOSS 332/545/552 HD
EN
10 - Pag. 7 / 16
øB (mm)
Guide channel
diameter
øC (mm)
Bar pusher
diameter
Collet version –
D
(type of coupling)
øGR (mm)
Revolving tip
diameter
Revolving tip
code
10 10 D71151010
12
Threaded
(IEMCA)
12 D71151210
10 10 D71151011
13
12
With quick
coupling pin
12 D71151211
15 D71151510
15
Threaded
(IEMCA)
16 D71151610
15 D71151511
17
15
With quick
coupling pin
16 D71151611
18 18 D71151810
19
Threaded
(IEMCA)
19 D71151910
20 20 D71152010
18
With quick
coupling screw
18 D71151811
19 19 D71151911
21
20
With quick
coupling pin
20 D71152011
23 23 D71152310
25
Threaded
(IEMCA)
25 D71152510
23 23 D71152311
26
25
With quick
coupling pin
25 D71152511
25 25 D71152510
27
Threaded
(IEMCA)
27 D71152710
23 23 D71152311
25 25 D71152511
28
27
With quick
coupling pin
27 D71152711
30 30 D70153010
31 31 D70153110
32
Threaded
(IEMCA)
32 D70153210
30 30 D70153011
31 31 D70153111
32
With quick
coupling screw
32 D70153211
30 30 D70153010
31 31 D70153110
33
32
With quick
coupling pin
32 D70153210
32 32 D70153210
35
Threaded
(IEMCA)
35 D70153510
32 32 D70153211
35
With quick
coupling screw
35 D70153511
32 32 D70153210
36
35
With quick
coupling pin
35 D70153510
