10 - GUIDE CHANNELS - BAR PUSHER - REVOLVING TIPS BOSS 332/545/552 HD
10 - Pag. 8 / 16
øB (mm)
Guide channel
diameter
øC (mm)
Bar pusher
diameter
Collet version –
D
(type of coupling)
øGR (mm)
Revolving tip
diameter
Revolving tip
code
Threaded
(IEMCA)
D70153710
With quick
coupling screw D70153711
38 37
With quick
coupling pin
37
D70153710
40 40 D70154010
Threaded
(IEMCA)
D70154210
With quick
coupling screw D70154211
43
42
With quick
coupling pin
42
D70154210
42 42 D70154210
45
Threaded
(IEMCA)
45 D70154510
42 42 D70154211
45
With quick
coupling screw
45 D70154511
42 42 D70154210
46
45
With quick
coupling pin
45 D70154510
Threaded
(IEMCA)
D70155110
With quick
coupling screw D70155111
52 51
With quick
coupling pin
51
D70155110
