CUSA EXcel Ultrasonic Surgical Aspirator System Service Manual xiii
List of Figures
Figure 2-1. The pre-aspiration holes and threads on tips 2-3
Figure 2-2. The three handpieces in the CUSA Excel system 2-5
Figure 4-1. Console structural features 4-2
Figure 4-2. Control panel features 4-4
Figure 4-3. Control panel features (continued) 4-6
Figure 4-4. Console body—front view 4-8
Figure 4-5. Console body—view of the right side 4-10
Figure 4-6. Console—rear view 4-12
Figure 4-7. Console—rear view (continued) 4-14
Figure 4-8. Control panel symbols 4-16
Figure 6-1. The handpiece components 6-2
Figure 6-2. Reserve power vs. TissueSelect settings 6-7
Figure 6-3. Reserve power vs. amplitude setting 6-9
Figure 7-1. The display organization on the control panel 7-3
Figure 9-1. Cleaning the handpiece with a soft cloth 9-4
Figure 9-2. Replacing the handpiece connector o-rings 9-5
Figure 11-1. Right and left sides of the console 11-3
Figure 11-2. The wiring harness on the system 24 volt power supply 11-7
Figure 11-3. Cables on the ultrasonics PCB assembly 11-9
Figure 11-4. The ultrasonics PCB fan assembly connections 11-10
Figure 11-5. Plugging the adapter for the syphon valve cable assembly into the
connector at J6 on the ultrasonics PBC
11-11
Figure 11-6. Disconnecting control panel assembly cables 11-13
Figure 11-7. Removing the Machine Control PCB from the control panel
assembly
11-14
Figure 11-8. The layers of control head components 11-16
Figure 11-9. Disconnecting control panel cables 11-17
Figure 11-10. Disconnecting the 50-pin ribbon cable and removing the Machine
Control PCB
11-19
Figure 11-11. Removing the Display PCB from the control head assembly 11-19
Figure 11-12. Removing the ends from the suction pump chamber 11-23
Figure 11-13. Removing the suction pump enclosure from the console 11-23
Figure 11-14. Disconnecting the suction tube at the contamination guard 90°
elbow
11-24
Figure 11-15. Disconnecting the suction tube from the left end of the suction
control valve
11-24
