Intermec EasyCoder PM4i User Manual

Chapter 9 — Options
EasyCoder PM4i Printer User’s Guide (Fingerprint Version) 87
Font Card
This is a CompactFlash memory card loaded with fonts. With a
Font Card installed, the user gets access to double-byte font sets
including Kanji, Korean and Chinese.
CompactFlash Protection Plate
The protection plate encloses an inserted CompactFlash card and
makes it more difficult to steal. See Chapter 3 for illustration.
Can be installed by the operator.
RFID Kit
The EasyCoder PM4i can be equipped with the capability to read
and write data to labels fitted with RFID (Radio Frequency
IDentification) inlays. RFID Kits come either factory installed or
as a field-installable option.
Special Printheads
As standard, the printer is fitted with an 8 dots/mm (203.2 dots/
in) thermal printhead. There are also a number of optional
printheads for special applications. The printhead can easily be
replaced or exchanged by the operator as described in Chapter
11.
8 dots/mm (203.2 dots per inch)
Media Thickness Standard/Option
Max 175
μm (7 mils) Standard
170-220 μm (6.6-8.7 mils) Option
170-220
μm (6.6-8.7 mils)
3 mm offset
Option
11.81 dots/mm (300 dots per inch)
Media Thickness Standard/Option
Max 175
μm (7 mils) Option
170-220 μm (6.6-8.7 mils) Option

Intermec EasyCoder PM4i Specifications

General

Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Display	LCD
Product color	Silver
Standard interfaces	RS-232, USB 2.0
Internal memory	16 MB
Media thickness	2.5/8.7 mm
Maximum label width	114.3 mm
Maximum label length	4 m
Maximum roll diameter	213 mm
Maximum internal memory	1 GB
Supported network protocols	TCP/IP, LPR/LPD, FTP, BOOTP, DHCP, HTTP, SNMPv3, SMTP, SNMP-MIB II
Power requirements	90 - 265 VAC, 45 - 65Hz
Power consumption (standby)	15 W
Power consumption (printing)	125 W
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	40 - 104 °F
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Depth	543 mm
Width	298 mm
Height	261 mm
Weight	13500 g
