Appendix B — Media Specifications
136 EasyCoder PM4i Printer User’s Guide (Fingerprint Version)
⇐ c ⇒ LSS Detection Position
Variable, see Chapter 11.
⇐ d ⇒ Detection Slit Length
The length of the detection slit (excluding corner radii) must be
minimum 2.5 mm (0.10 in) on either side of the LSS detection
position (e).
⇐ e ⇒ Detection Slit Height
Media Type Setup
• Ticket (w gaps)
Tickets With Black Mark
⇐ a ⇒ Media Width
⇐ b ⇒ Copy Length
⇐ c ⇒ LSS Detection Position
Variable, see Chapter 11.
⇐ d ⇒ Black Mark Width
The detectable width of the black mark should be at least 5.0 mm
(0.2 in) on either side of the LSS detection point.
⇐ e ⇒ Black Mark Length
Maximum: 21.3 mm (0.83 in)
Recommended: 1.6 mm (0.06 in)
Minimum: 1.2 mm (0.05 in)
Note: Do not allow any perforation to break the edge of the
media as this may cause the media to split and jam the printer.
Maximum: 114.3 mm (4.50 in)
Minimum: 25.0 mm (1.00 in)
Minimum: 20.0 mm (0.8 in)
Maximum: depends on SDRAM size
Maximum:
21.3 mm (0.83 in)
