Intermec EasyCoder PM4i User Manual

Chapter 2 — Installation
EasyCoder PM4i Printer User’s Guide (Fingerprint Version) 13
Indicator Lamps
The indicators are colored LEDs (Light Emitting Diodes) and are
used for the following purposes:
The Intermec Ready-to-Work Indicator
™ helps users quickly
determine the readiness of the Intermec device individually and
as part of a solution. The Intermec Ready-to-Work Indicator has
three different states: On, Blinking, and Off. When the Indicator
is off, the device is not ready to operate individually or as part of
a solution. When the Indicator is blinking, the device may be
initializing, waiting for external resources, or in need of user
attention. And when the Indicator is On, the device is ready for
use as part of a solution. Also see Chapter 9.
Display
The display window contains an LCD (Liquid Crystal Display)
with background illumination and two lines of text, each with 16
characters. It provides information on installed firmware or
running application, prompts the operator in Intermec Shell and
in the Setup Mode, and can show information on possible errors
and active communication channels.The Intermec Fingerprint
programming language and the Intermec Direct Protocol allow
custom-made messages to be composed and displayed according
to the requirements of the application.
LED State Description
Power Solid green Indicates that the
power is on.
Status Solid green Indicates that the
printer is ready for use.
Status Flashing green Indicates that the
printer is
communicating.
Status Solid red Indicates an error
condition
(see“Troubleshooting”
on page 89).
Intermec Ready-to-
Work Indicator
On, blinking, or off Determines the
readiness of the
Intermec device.

Intermec EasyCoder PM4i Specifications

General

Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Display	LCD
Product color	Silver
Standard interfaces	RS-232, USB 2.0
Internal memory	16 MB
Media thickness	2.5/8.7 mm
Maximum label width	114.3 mm
Maximum label length	4 m
Maximum roll diameter	213 mm
Maximum internal memory	1 GB
Supported network protocols	TCP/IP, LPR/LPD, FTP, BOOTP, DHCP, HTTP, SNMPv3, SMTP, SNMP-MIB II
Power requirements	90 - 265 VAC, 45 - 65Hz
Power consumption (standby)	15 W
Power consumption (printing)	125 W
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	40 - 104 °F
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Depth	543 mm
Width	298 mm
Height	261 mm
Weight	13500 g
