Intermec EasyCoder PM4i User Manual

Appendix B — Media Specifications
134 EasyCoder PM4i Printer User’s Guide (Fingerprint Version)
Self-Adhesive Labels
⇐ a ⇒ Media Width (including liner)
⇐ b ⇒ Liner
The backing paper must not extend more than a total of 1.6 mm
(0.06 in) outside the labels and should protrude equally on both
side. Recommended minimum transparency: 40% (DIN 53147).
⇐ c ⇒ Label Width (excluding liner)
⇐ d ⇒ Label Length
Under ideal circumstances, a minimum label length of 4 mm
(0.16 in) could be used. It requires the sum of the label length (d)
and the label gap (e) to be larger than 7 mm (0.28 in), that batch
printing is used, and that no pull back of the media is performed.
Intermec does not guarantee that such short labels will work, but
it is up to the user to test this in his unique application.
⇐ e ⇒ Label Gap
The Label Stop Sensor must be able to detect the extreme front
edges of the labels.
Media Type Setup
•Label (w gaps)
Maximum:
114.3 mm (4.50 in)
Minimum:
25.0 mm (1.00 in)
Maximum: 112.7 mm (2.30 in)
Minimum: 23.8 mm (0.94 in)
Maximum: depends on SDRAM size
Minimum: 8.0 mm (0.32 in)
Maximum: 21.3 mm (0.83 in)
Recommended: 3.0 mm (0.12 in)
Minimum: 1.2 mm (0.05 in)

Intermec EasyCoder PM4i Specifications

General

Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Display	LCD
Product color	Silver
Standard interfaces	RS-232, USB 2.0
Internal memory	16 MB
Media thickness	2.5/8.7 mm
Maximum label width	114.3 mm
Maximum label length	4 m
Maximum roll diameter	213 mm
Maximum internal memory	1 GB
Supported network protocols	TCP/IP, LPR/LPD, FTP, BOOTP, DHCP, HTTP, SNMPv3, SMTP, SNMP-MIB II
Power requirements	90 - 265 VAC, 45 - 65Hz
Power consumption (standby)	15 W
Power consumption (printing)	125 W
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	40 - 104 °F
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Depth	543 mm
Width	298 mm
Height	261 mm
Weight	13500 g
