Intermec EasyCoder PM4i User Manual

Chapter 2 — Installation
14 EasyCoder PM4i Printer User’s Guide (Fingerprint Version)
Keyboard
The keyboard is of the membrane-switch type and has 22 keys.
The keyboard is supplemented by a large Print button. Some
keys have hard-coded functions in the startup and setup
modes.In application programs created using the Intermec
Fingerprint programming language, the keys can be assigned to
various functions or be disabled individually. Since one key is
assigned as shift key, up to 44 different key combinations are
possible. An audible signal, which can be turned off if so desired,
acknowledges that a key has been pressed.
Button Function
Print button Feed/Pause a print job. Repeat last printed
label.
Toggle between pause and printing when
executing a print job.
+
Interrupt a running Fingerprint program.
Enter the Setup Mode (For help, see
“Setup Mode” on page 69.).
Feed out a blank label or the equivalent.
Perform a Testfeed (feed a blank label,
adjust the media feed).
Display error messages, Ready-to-Work
status, and communication channel
information.
Scroll between various types of
information after pressing the F5/i key.
Possible error messages and information
on active communication channels are
shown in a loop.
+
+

Intermec EasyCoder PM4i Specifications

General

Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Display	LCD
Product color	Silver
Standard interfaces	RS-232, USB 2.0
Internal memory	16 MB
Media thickness	2.5/8.7 mm
Maximum label width	114.3 mm
Maximum label length	4 m
Maximum roll diameter	213 mm
Maximum internal memory	1 GB
Supported network protocols	TCP/IP, LPR/LPD, FTP, BOOTP, DHCP, HTTP, SNMPv3, SMTP, SNMP-MIB II
Power requirements	90 - 265 VAC, 45 - 65Hz
Power consumption (standby)	15 W
Power consumption (printing)	125 W
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	40 - 104 °F
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Depth	543 mm
Width	298 mm
Height	261 mm
Weight	13500 g
