Intermec EasyCoder PM4i User Manual

Appendix B — Media Specifications
EasyCoder PM4i Printer User’s Guide (Fingerprint Version) 135
Tickets With Gaps
⇐ a ⇒ Media Width
⇐ b ⇒ Copy Length
Under ideal circumstances, a minimum ticket length of 4 mm
(0.16 in) could be used. It requires the sum of the copy length (b)
and the detection slit height (e) to be larger than 7 mm (0.28 in),
that batch printing is used, and that no pull back of the media is
performed. Intermec does not guarantee that such short tickets
will work, but it is up to the user to test this in his unique
application.
a
b
c
e
b
d
Maximum: 114.3 mm (4.50 in)
Minimum: 25.0 mm (1.00 in)
Max. length between slots: depends on SDRAM size
Min. length between slots: 8.0 mm (0.32 in)

Intermec EasyCoder PM4i Specifications

General

Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Display	LCD
Product color	Silver
Standard interfaces	RS-232, USB 2.0
Internal memory	16 MB
Media thickness	2.5/8.7 mm
Maximum label width	114.3 mm
Maximum label length	4 m
Maximum roll diameter	213 mm
Maximum internal memory	1 GB
Supported network protocols	TCP/IP, LPR/LPD, FTP, BOOTP, DHCP, HTTP, SNMPv3, SMTP, SNMP-MIB II
Power requirements	90 - 265 VAC, 45 - 65Hz
Power consumption (standby)	15 W
Power consumption (printing)	125 W
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	40 - 104 °F
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Depth	543 mm
Width	298 mm
Height	261 mm
Weight	13500 g
