Intermec EasyCoder PM4i User Manual

Chapter 11 — Maintenance
98 EasyCoder PM4i Printer User’s Guide (Fingerprint Version)
Printhead Cleaning
Cleaning the printhead on a regular basis is important for the life
of the printhead and for the printout quality. You should clean
the printhead each time you replace the media. This section
describes how to clean the printhead using cleaning cards. If
additional cleaning is required, for example removing adhesive
residue from the platen roller or tear bar, use a cotton swab
moistened with isopropyl alcohol.
To clean the printhead
1 Open the front and side doors.
Isopropyl alcohol [(CH 3)2CHOH; CAS 67-63-0] is a highly
flammable, moderately toxic, and mildly irritating substance.

Intermec EasyCoder PM4i Specifications

General

Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Display	LCD
Product color	Silver
Standard interfaces	RS-232, USB 2.0
Internal memory	16 MB
Media thickness	2.5/8.7 mm
Maximum label width	114.3 mm
Maximum label length	4 m
Maximum roll diameter	213 mm
Maximum internal memory	1 GB
Supported network protocols	TCP/IP, LPR/LPD, FTP, BOOTP, DHCP, HTTP, SNMPv3, SMTP, SNMP-MIB II
Power requirements	90 - 265 VAC, 45 - 65Hz
Power consumption (standby)	15 W
Power consumption (printing)	125 W
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	40 - 104 °F
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Depth	543 mm
Width	298 mm
Height	261 mm
Weight	13500 g
