Intermec EasyCoder PM4i User Manual

Appendix B — Media Specifications
130 EasyCoder PM4i Printer User’s Guide (Fingerprint Version)
Media Roll Size
Core
Millimeters/Inches
Diameter (A), standard: 38-40 mm (1.5 in)
Diameter (A), with adapter: 76.2 mm (3 in)
Width: Must not protrude outside the media.
The media must be wound up on the core in such a way that
the printer can pull the end free.
Roll
Millimeters/Inches
Max. diameter (B): 213 mm (8.38 in)
Max. width (C): 114.3 mm (4.50 in)
Min. width, standard (C): 25 mm (1.00 in)
Min. width, fanfold guides (C): 40 mm (1.57 in)

Intermec EasyCoder PM4i Specifications

General

Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Display	LCD
Product color	Silver
Standard interfaces	RS-232, USB 2.0
Internal memory	16 MB
Media thickness	2.5/8.7 mm
Maximum label width	114.3 mm
Maximum label length	4 m
Maximum roll diameter	213 mm
Maximum internal memory	1 GB
Supported network protocols	TCP/IP, LPR/LPD, FTP, BOOTP, DHCP, HTTP, SNMPv3, SMTP, SNMP-MIB II
Power requirements	90 - 265 VAC, 45 - 65Hz
Power consumption (standby)	15 W
Power consumption (printing)	125 W
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	40 - 104 °F
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Depth	543 mm
Width	298 mm
Height	261 mm
Weight	13500 g
