Intermec EasyCoder PM4i User Manual

Appendix B — Media Specifications
EasyCoder PM4i Printer User’s Guide (Fingerprint Version) 131
The maximum recommended media thickness is 175 μm (7 mils)
with the standard printhead or 220
μm (8.7 mils) with a special
printhead. Thicker media may be used, but print quality will be
reduced. The stiffness is also important and must be balanced
against thickness to maintain print quality.
Media rolls to be loaded inside the printer should be wound with
the printable side facing outwards.
The media supply must not be exposed to dust, sand, grit, etc.
Any hard particles, however small, can damage the printhead.
Media
Media with RFID Tags/Inlays
When printing on RFID media, special consideration must be
taken to the position and shape of the tag. Specific
recommendations for different kinds of Intermec-approved
RFID media can be found on the Intermec website. Additional
information is provided in the documentation that came with
your RFID kit.
Non-Adhesive Strip
⇐ a ⇒ Media Width
Media Type Setup
•Fix length strip
•Var length strip
Maximum: 114.3 mm (4.50 in)
Minimum: 25.0 mm (1.00 in)

Intermec EasyCoder PM4i Specifications

General

Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Display	LCD
Product color	Silver
Standard interfaces	RS-232, USB 2.0
Internal memory	16 MB
Media thickness	2.5/8.7 mm
Maximum label width	114.3 mm
Maximum label length	4 m
Maximum roll diameter	213 mm
Maximum internal memory	1 GB
Supported network protocols	TCP/IP, LPR/LPD, FTP, BOOTP, DHCP, HTTP, SNMPv3, SMTP, SNMP-MIB II
Power requirements	90 - 265 VAC, 45 - 65Hz
Power consumption (standby)	15 W
Power consumption (printing)	125 W
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	40 - 104 °F
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Depth	543 mm
Width	298 mm
Height	261 mm
Weight	13500 g
