Intermec EasyCoder PM4i User Manual

Chapter 11 — Maintenance
EasyCoder PM4i Printer User’s Guide (Fingerprint Version) 111
Media Jams
Should a media jam occur in the print mechanism, proceed this
way to clear it:
• Always switch off the power before starting to clear the
jammed media.
• Raise the printhead and pull out the media.
• If the media has been wound up or has stuck on the platen
roller, carefully remove it by hand without using any sharp
tools that can damage the delicate platen roller or printhead.
Avoid rotating the platen roller.
• Cut off any damaged or wrinkled part.
• Check if there is any adhesive somewhere in the print
mechanism, clean using a cleaning card or cotton swab soaked
in isopropyl alcohol.
• Reload the media as described in Chapter 4.
• Switch on the power.
• Readjust the media feed by pressing the Feed button.
If you must pull away the media by force causing the platen
roller to rotate, it is very important that the power has been
off for a minute or more. If not, the electronics can be
damaged beyond repair.
Isopropyl alcohol [(CH-3)2CHOH; CAS 67-63-0] is a highly
flammable, moderately toxic, and mildly irritating substance.

Intermec EasyCoder PM4i Specifications

General

Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Display	LCD
Product color	Silver
Standard interfaces	RS-232, USB 2.0
Internal memory	16 MB
Media thickness	2.5/8.7 mm
Maximum label width	114.3 mm
Maximum label length	4 m
Maximum roll diameter	213 mm
Maximum internal memory	1 GB
Supported network protocols	TCP/IP, LPR/LPD, FTP, BOOTP, DHCP, HTTP, SNMPv3, SMTP, SNMP-MIB II
Power requirements	90 - 265 VAC, 45 - 65Hz
Power consumption (standby)	15 W
Power consumption (printing)	125 W
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	40 - 104 °F
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Depth	543 mm
Width	298 mm
Height	261 mm
Weight	13500 g
