Intermec EasyCoder PM4i User Manual

Chapter 2 — Installation
8 EasyCoder PM4i Printer User’s Guide (Fingerprint Version)
Media Compartment
Description
The media compartment is completely covered by a door that
can be opened 180° upwards to provide full access for media and
ribbon load and has an inspection window for checking the
media and transfer ribbon supplies.
The media can be supplied from a post or, optionally, from an
external supply of fan folds behind the printer using an internal
media guide device. There is also an optional rotating media
supply hub. Also see “Options” on page 83.
Thermal transfer
mechanism
Lock
(option)
Side
door
Inspection
window
Integral liner
takeup
Slack
absorber
Print
mechanism
Front
door
Keyboard
Media supply
roll post with
edge guide

Intermec EasyCoder PM4i Specifications

General

Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Display	LCD
Product color	Silver
Standard interfaces	RS-232, USB 2.0
Internal memory	16 MB
Media thickness	2.5/8.7 mm
Maximum label width	114.3 mm
Maximum label length	4 m
Maximum roll diameter	213 mm
Maximum internal memory	1 GB
Supported network protocols	TCP/IP, LPR/LPD, FTP, BOOTP, DHCP, HTTP, SNMPv3, SMTP, SNMP-MIB II
Power requirements	90 - 265 VAC, 45 - 65Hz
Power consumption (standby)	15 W
Power consumption (printing)	125 W
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	40 - 104 °F
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Depth	543 mm
Width	298 mm
Height	261 mm
Weight	13500 g
